IOS iPad / iPhone, Android, Windows
- Connect to your iOS or Android, or both.
Primary Care
Emergency
EMS
Veterinary
Wellness
Interventional
Med School
OBGYN
Anesthesia
Breast
Pain Management
Clinical Research
FULL-BODY DIAGNOSTIC IMAGING
SMALL, LIGHT AND CONVENIENT
Point-Of-Care Imaging In The Palm Of Your Hand
SMALL, LIGHT AND CONVENIENT
With only about 90g (0.19lbs), it contains everything you need to image a full human body. Put it in your pocket and bring it to the bedside of every patient. Designed for more remotable and efficient diagnosis.
Completely Wireless For Efficient Disinfection
3 in 1 Wireless Portable Color Doppler Ultrasound makes your practices fully wireless and easy to disinfect in a short time. It supports wireless charging. Help to reduce the risk of infection during Pandemic. This handheld ultrasound scanner with a built-in wifi signal is able to connect to both iPhones and Android phones.
FULL BODY-Point-of Care Imaging
3 in 1 Wireless Portable Color Doppler Ultrasound works as a multipurpose wireless dual head convex+linear+cardiac ultrasound probe. Simply flip the device, you can switch from shallow exams to deep exams.
From the deep structures within the abdomen, superficial anatomy, the extremities and even to the heart.
3 in 1 Wireless Portable Color Doppler Ultrasound Convex+
Linear+ Cardiac Probe
The 3 in 1 Wireless Portable Color Doppler Ultrasound is a combination of two probes, one side of the convex array probe and the other side of the line array probe, and the convex array probe has a cardiac preset function. One Wireless ultrasound scanner with dual probe, 3 in 1 multipurpose handheld convex+linear+cardiac Ultrasound probe can diagnose whole body parts.
Features of 3 in 1 Wireless Portable Color Doppler Ultrasound Convex+ Linear probe
Dual head convex + linear + cardiac preset 3 in 1 probe
Only 120g, smaller than iphone, easy to carry
B, B+B, B/M, Color, PW, PDI, B+Color+PW mode
WiFi&USB, 2 connection methods, support working while charging
What Professionals are Saying
Dr. Sean Tibor
"This device offers very good image quality, settings, and modes for a reasonable price. Advanced imaging settings with several imaging modes Aesthetic, somehow light and not clunky.
Dr. Jean George
"Through my personal experience of wireless dual head ultrasound from Ranealth, results were very good and the picture quality is good..." perfect for me and my patient needs!
Manuel Fallon
"It's really cool because it's very quick to connect with my ipad or my phone. It pretty much does everything that you could think of. It is great for
doctor's offices.
See Clinical Images In Crisp & Clear
Rapidly identify patients' anatomy on your phone. Get fast ultrasound images in HD.
- Cardiac
- Carotid
- Liver
- Vascular
Cardiac
Cardiac Live
Carotid
Carotid Live
Liver
Liver with Color Doppler (live)
Wrist Vessel
Wrist vessel with Color Doppler (live)
Clinical Images
- recorded by 3 in 1 Wireless Portable Color Doppler Ultrasound
- Kidney
- Liver
- Carotid & Thyroid
- Vascular
- Fetus
- Cardiac
Kidney with Color Doppler
Kidney Live with Color Doppler
Liver
Liver with Color Doppler (live)
Liver with Color Doppler
Bile accumulation in liver (cholestasis)
Carotid
Carotid with Pulsed Wave Doppler
Carotid with Color Doppler
Carotid with Color Doppler (live)
Vascular access with Color Doppler
Vascular puncture with venous thrombosis
Fetus
Cardiac
Cardiac Live
Get fast ultrasound images in seconds
Press the centered button of your probe, pause anytime during your scanning detect unusual events that happen to patients. Capture clinical images, video clips and get detailed measurements in seconds.
Small Probe With Great Capablity
3 Arrays, 5 Imaging Modes, 16+ Presets
Compatibility
3 Transducer Probes
3 types of transducers are included: linear, convex and phased array ultrasound probe. Handheld ultrasound scanner can do vascular access and work as a cardiac ultrasound probe at the same time.
Linear
Convex
Phased (Cardiac)
Imaging Modes
Choose the mode you want in B-mode, M-mode, Color Doppler, Power Doppler, and Pulsed Wave Doppler. No extra fees are required.
Adjustable Depth & Frequency
Up to 305mm of depth to adjust
- 20mm/40mm/60mm/90mm/ 100mm/160mm/220mm/305mm
4 Switchable frequencies:
- 3.5MHz
- 5MHz
- 7.5MHz
- 10MHz
Flexible noise decreasemens and gain values to fit the best of image quality
Flexible focus positions, TGC, and gain to fit the best of image quality.
Detect Every Small
Abnormality on Phone
Pause anytime during your scanning process to detect unusual events that happen to patients. Capture clinical images, video clips and get detailed measurements in seconds.
Pulsed Wave
Doppler Adopted
Get measured velocity point
to point on your screen with our built-in
Pulsed Wave Doppler.
Share Diagnostic Results with Notes
Manage patient's data on app. Save image or clips to the photo gallery of smartphones or tablets. Then share results with colleagues via Airdrop (file transmit function between iOS devices) or text messages.
Quick Measurements
On Screen
Identify abnormalities easily and get length, angle, area and trace measurements right away.
One Scanner, Fulfill 16+ Specialties
Up to 305mm scanning depth, adjustable frequency levels, designed for comprehensive ultrasound exams.
LINEAR
Vascular
MSK
Pediatrics
Breast
Carotid
Thyroid
Small Parts
Nerve
CONVEX
Abdomen
Cardiac
Gynecology
Obstetric
Urology
Kidney
Lung
Connect to your iOS or Android, or both.
CHECK ULTRASOUND IMAGES ON SMARTPHONES AND TABLETS
Why Our 3 in 1 Wireless Portable Color Doppler Ultrasound ?
2.5X FASTER
2-hour flash recharge for your shift.
1.4X LIGHTER
With only 90g (0.19lbs), we're way more portable than others.
SMALL SIZE
Due to its small size, you can put it in your pocket during your shifts and transit to every floor room effortlessly.
NO MEMBERSHIP
No extra fees for any service, one-time purchase for all you need.
Point-of-care imaging in your pocket.
With only about 90g (0.19lbs), this 3 in 1 Wireless Portable Color Doppler Ultrasound enables clinicians to easily image patients at the point of care. Put it in your pocket and bring it to the bedside of every patient.
See more. treat faster.
A wireless, lightweight handheld ultrasound system that enables the flexible Performance of whole body scanning and delivers crystal-clear images. The 3 in 1 Wireless Portable Color Doppler Ultrasound is easy to use, intuitive to navigate and optimized for your mobile device.
Authorized
We use technologies trusted by hospitals and clinics.
User-Friendly
We design products for users, we design products for our users that are user friendly.
Innovative
We keep exploring, to create innovations for professional healthcare.
Patient & Doctor
We make doctor-patient closely connect, by providing accuracy and intelligence.
186
Our users cover 186 countries worldwide
100000
Over 100000 doctors worldwide use our ultrasound
What's Included?
- 1x 3 in 1 Wireless Portable Color Doppler Ultrasound
- 1x USB Charger
- 1x Plug
- 1x Wireless Charger
- 1x Wrist Strap
- 1x Portable Alluminum Alloy Box
Full Specification of
Dual-probes Multipurpose
Ultrasound convex+linear+cardiac probe
Probe | Wireless dual head convex+linear probe |
Elements | Dual 128 |
Frequency | 3.5/5.0mhz, 7.5/10mhz,2.5/5.0mhz |
Depth | 90-305mm, 20-100mm, 90-160mm |
Preset 16+ | Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, User1, User2 |
Host | Tablet, Smart phone, PC |
Connection | WiFi&USB |
Software Adjustable Parameters | GN(gain), D(Depth), ENH(Enhancement), DR(Dynamic range), F(Frequency), FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote, Page left/right/up/down. |
Measurement | B: Length, Area/Circumference, Angle, Trace, Distance GA(CRL,BPD,GS,FL,HC,AC)EFW(BPD,FL) |
Playback Frames | 100, 200, 500, 1000 optional |
Display Mode | B, B+B, B/M, Color, PW, PDI, B+Color+PW |
Image Gray Scale | 256 level |
WiFi Type | Built-in WiFi, 802.11g/20MHz/2.4G/5G/450Mbps |
Channel | 64 |
Frame | 24f/s |
Gain | 40-110Db |
Language | English, Chinese,Russian, German, Italian, Frence, Ukrainian, Spanish, Portuguese |
Power | by built-in Lithium battery |
Battery Replaceable | Yes |
Battery Last | 3hours (Working time), 12 hours(Stand by time) |
Charger | USB Charger, wireless charger |
Waterproof Grade | IPX5 |
Scanning Mode:
Convex, Phased (Cardiac), Linear
Frequency:
Convex 3.5/5 MHz; Phased (Cardiac) 2.5/5 MHz, Linear 7.5/10 MHz
Depth:
Convex 90/160/220/305mm; Phased (Cardiac) 90/120/140/160mm; , Linear 20/40/60/100mm
Elements:
128
Radius / Footprint:
Convex R45, Phased (Cardiac) R45,
Linear L24
Focus:
0.1.2.3
Image Enhancement:
0.1.2.3.4
TGC:
8TGC
Application:
Vascular, MSK, Pediatrics, Breast, Carotid, Thyroid, Small Parts, Nerve, Abdomen, Cardiac, Gynecology, Obstetric, Urology, Kidney, Lung
Dynamic Range:
40-110 Db
Measure:
B: Length, Area/Circumference, Angle, Trace, Distance, GA (CRL, BPD, GS, FL, HC, AC), EFW (BPD, FL)
B+M: Heart Rate, Time, Distance
B+PW: Velocity, Heart Rate(2), S/D, Depth
Charge:
Type-c Cable or wireless charge, 2h
Display Mode:
B, B/M, Color Doppler, PW, Power Doppler
Gain:
30-105 Db
Power Consumption:
10W (probe run) / 2W (probe stop)
Image Gray Scale:
256 level
Battery Capacity:
Lithium Battery 2800mAh, Working time ≥3h, Standby time: ≥12h, supporting working while charging
Image Frame Rate:
20 f/s
Language:
English, Italian, Spanish, Portuguese, German, French, Russian, Chinese
Size:
125(h) x 70(w) x 20(d) mm
Weight:
90g (0.19lbs)
Compatibility:
IOS iPad / iPhone, Android, Windows
Image Format:
JPG, AVI, MP4, DICOM
Software Controls:
GN (gain), D (depth), ENH (enhancement), DR (dynamic range), F(frequency), PRF, WF, Focus, Mode B, B/M, Color Doppler, PW, Power Doppler, Biopsy, Page Left/Right, Up/Down, 8TGC
Package:
Aluminum Box with Lock
Connection:
2.4G/5G, WIFI, USB
Cleaning
Caution
- The probe cannot be immersed in any conductive liquid, so as not to corrode the probe and sheath.
- The depth of the probe immersed in water shall not exceed the mark of the probe immersion line, and check the probe shell for cracks to avoid damage to internal components by liquid immersion.
- Before cleaning the probe, make sure that the probe is powered off.
Steps
- After each use of the probe, use a soft cloth dampened with Isopropyl alcohol (or an appropriate hospital cleaning agent) to clean the probe.
- Disconnect the probe from the mobile device.
- Wipe the probe for one minute until it is visibly clean.
- Change wipes when necessary and repeat step 3 until the probe is visibly clean.
- Visually inspect the probe in a well-lit area to ensure all surfaces are clean.
- If the probe is not clean, repeat the steps above.
FAQ
Shipping
We offer free shipping. The referenced transit time is 2-10 business days.
Note: affected by Covid-19, there will be some delay on the delivery.
Maintenance Warranty
Our company guarantees the new instrument on the material and technological qualification for this product within 18 months and the accessories within 6 months since the purchasing day, while consumables are not included in the guarantee. This warranty is inapplicable to the products undergoing any modifications, disassembles, refittings or self-repairings without the permission of our company. We're not responsible of the products damaged by accidents such as fire, thunder and lightning, flood and other disasters, intentional damage, improper installation, and improper usage. If you need help with maintenance, or you want to purchase our product in large quantities, please contact us.
3 in 1 Wireless
Portable Color
Doppler Ultrasound
Get your 3 in 1 Wireless Portable Color
Doppler Ultrasound now.
One time purchase. No required membership.
0 Membership Fee
Unlimited Users
18-Month Warranty
